Foreground and Background Agents

Realtime voice mode uses two cooperating agents:

• The realtime voice model is the foreground agent. It owns the live conversation and must not wait for device operations or long-running work.
• The legacy agent loop is the background agent. It executes queued tasks one at a time with the existing runtime tools, memory, and episode recording.

The orchestration layer lives in internal/agenttask. It owns task data, state transitions, queueing, cancellation, and terminal notifications without depending on internal/agent. The daemon supplies a narrow runner adapter that maps Run(ctx, prompt) to the legacy agent.Runtime.

The two conversation contexts are persisted separately under the configured session root: sessions/user contains the realtime foreground conversation, while sessions/backend contains the legacy device-operation context. The user context also persists the realtime foreground's own tool calls and tool results, so they can be restored when a new realtime websocket session is opened. Backend tool traces remain isolated in sessions/backend; only their aggregated task updates are injected into the foreground as user messages. To keep realtime context bounded, a new websocket session replays only the latest 10 user turns, including the assistant/tool messages belonging to those turns. The full user history remains on disk.

The foreground realtime session can be activated by either the physical GPIO wakeup signal or a text request to /api/chat. A text request submitted while no realtime session is connected stays queued while the daemon connects, then becomes the first user message in that session. GPIO initialization failure does not disable /api/chat activation, which keeps the same foreground path usable on PC and other hosts without board GPIO.

An outstanding foreground response has a 60-second no-progress timeout. Accepted assistant text/audio and foreground tool calls/results renew that deadline; microphone traffic, input transcript refinements, usage reports, and stale response events do not. Foreground tools retain their separate 30-second execution timeout. An idle conversation with no pending turn is not timed out. Timeouts fail the pending text request and close the realtime session, including its playback and foreground tool context. Explicit cancellation uses the provider's ResponseInterrupter when available, stops playback and foreground tools, and retains admission ownership until the terminal acknowledgement. Late output cannot renew the cancellation deadline. Unsupported interruption, a failed write, or a missing acknowledgement closes the session; the next request then reconnects and restores history. Successful cancellation keeps supported provider sessions connected. Background tasks have their own lifecycle and are not canceled by canceling a foreground response.

Gemini interrupts through clientContent with turnComplete=false, leaving the server waiting for input rather than requesting another answer. This follows Google's ClientContent interruption semantics without switching off automatic VAD (manual activityStart requires that switch). Gemini's interrupted followed by turnComplete is normalized to a canceled terminal response; the daemon retains the interrupted response's terminal ownership even when it has no ID, without consuming the new user's pending input. See the official protocol. The empty-content cancel payload is covered by a local WebSocket protocol test; its behavior against the deployed Gemini service still requires live validation. Gemini tool-call cancellation is scoped to the listed call IDs: it cancels those foreground invocations and drops their late results while preserving other parallel calls and the response lifecycle.

Chat admission logs include the incoming and active request IDs, response ID, occupancy duration, and each admission guard. Response completion, cancellation, timeout, and session release are logged separately for diagnosing busy reports.

Foreground tools

The realtime model receives this focused catalog:

Tool	Purpose
get_current_time	Return controller-local date, time, timezone, and UTC offset.
recall_memory	Recall long-term user preferences, facts, rules, and procedures.
save_memory	Save a long-term memory without waiting for a background task.
forget_memory	Delete a saved memory by the ID returned from recall_memory.
recall_session_chunks	Recall compressed history older than the replayed window.
audio_volume	Read or set the realtime playback volume.
create_agent_task	Queue background work and return immediately with a task ID.
cancel_agent_task	Cancel queued work or request cancellation of running work.
update_agent_task	Replace the complete goal of queued or running work.
query_agent_task	Read one task's state and result, or every outstanding task when no ID is given.
response_user_action	Resume a background task after the user completes the requested device action.
end_conversation	Return to standby after the farewell finishes playing.

create_agent_task only enqueues work. The foreground response never waits for the background agent to start or finish.

When the user changes work that is already outstanding, the foreground calls update_agent_task with the task ID and the complete replacement goal. It does not cancel the old task and create a new one. Queued work reads the replacement goal when it starts. Running work receives the replacement as an in-context steer: the current model or tool call is interrupted, the updated goal is added to the backend conversation as a user message, and the agent loop resumes with the same task ID and backend context.

Before creating work, the foreground calls query_agent_task without a task ID and continues the task that already covers the request instead of starting a duplicate. That check answers with the tasks that are still in flight plus the finished tasks whose result has not been delivered to the foreground yet; delivered results are left out because the foreground holds them in its own context, so asking for the same work later is a genuine new request. A repeated or reworded request therefore does not start the same device work twice.

The memory tools reuse the same registrations and stores as the background agent, so both agents read and write one memory plane. Their foreground descriptions are trimmed to the foreground catalog: the background recall_memory description points at shell for raw notification records, which the realtime model cannot call.

recall_session_chunks exists because a new websocket session replays only the latest 10 user turns. Older turns stay on disk but are invisible to the foreground until recalled.

Ending a conversation

end_conversation puts the session back into standby. It does not introduce a new state: runRealtimeSession returns, and the outer loop waits for the next GPIO wakeup or /api/chat activation, exactly as it does after any other session ends.

Teardown is deferred rather than immediate, because cancelling the session as soon as the tool returns would cut off the farewell mid-sentence:

1. The tool result only records the request; the session loop owns teardown.
2. On response.done for the farewell, playback is finalized and a drain starts, bounded by a 30 s timeout.
3. Standby begins once the drain reports the speaker is empty.

The request is abandoned if the user re-engages first, via either input_audio_buffer.speech_started or a text request through the chat bridge. Both keep the session open and answer the new input instead. A text request that arrives while the farewell response is still active is queued until its response.done; during playback drain it starts immediately. While a request is pending, task updates and voice notifications are not injected, so a queued result cannot start a new response during the goodbye.

Background work is unaffected by standby. A background task that reaches a terminal state while the foreground is in standby activates the foreground by itself, so the result is reported without the user having to speak first. The existing session teardown returns undelivered task updates and pending user actions to the manager; they are delivered by the next session, whether it was started by the task update or by the user. Activation is attempted once per terminal batch: if that session cannot deliver the update, it is returned to the queue and waits for the next activation instead of re-activating in a loop. A pending user action does not activate the foreground on its own; it is announced by the next session.

Task lifecycle

Tasks use the following states:

created -> queued -> running -> completed
                            -> failed
                            -> cancelling -> cancelled
                            -> running (waiting for user action)
                 -> cancelled

Queued cancellation is immediate. Running cancellation first publishes cancelling; it becomes cancelled after the legacy runtime returns from context cancellation.

Task updates follow these state rules:

• created or queued: replace the stored goal before execution.
• running: replace the stored goal and publish a latest-wins steer to the active backend run.
• running while waiting for user action: invalidate the old action request and resume the task with the replacement goal.
• cancelling or terminal: reject the update.

Every goal has a revision. Persisting a steer in the backend context advances the applied revision. If the backend run returns after an update but before persisting it, the manager discards that stale result and immediately runs the latest complete goal again. This closes the race between a direct final answer and an update arriving after the agent loop's last steer check.

Backend interruption context

Backend execution writes persisted notice messages when a run stops early, so the next model request can distinguish interrupted work from completed work. These notices belong to sessions/backend; frontend playback and task-result delivery retain their own lifecycle.

Situation	Notice and behavior
Cancel a running task, cancel a legacy chat request, STT wakeup cancellation, or service shutdown	Interrupt [canceled]; completion is not confirmed.
Another Runtime.Run takes over	Interrupt [preempted]. Creating a queued backend task does not preempt its predecessor.
Execution deadline expires	Interrupt [deadline_exceeded].
Update a running task or submit chat steer	Interrupt [steer] immediately before the replacement user instruction; the same run continues.
A model/tool call was interrupted but its steer was withdrawn or yielded no text	Interrupt [steer_resumed]; continue the original task from its last confirmed state.
Unrecovered model request failure	Interrupt [model_error].
Context budget, compaction, or other execution failure	Interrupt [execution_error].
Iteration/time budget, repeated actions, no progress, or repeated parsing failures	Interrupt with the loop guard's stop reason. Existing guard warnings and stop results remain available.
Incompatible device touch mode	Interrupt [device_mode_mismatch].
Runtime panic	Interrupt [panic], when persistence remains possible; the panic is rethrown.
Abrupt process exit with no recorded end	Interrupt [agent_restart], recovered before the next backend input; completion is unknown.
Successful request_user_action or wait_for_wakeup	Pause [...]; intentional suspension is not task completion.

The runtime atomically records .pending-run.json in sessions/backend before execution. It clears the record after a normal end or after persisting an interruption. A failed notice write leaves a recovery record; if recovery also fails, the next run reports the error instead of executing without that context. Recovery follows active compaction lineage, deduplicates notices, and preserves history rotation/clearing.

Notices are appended after tool results, preserving tool-call/result pairing. They tell the model to verify the current device state before repeating an action, because cancellation cannot undo side effects. Tools that ignore cancellation must return before the loop can record their result and finish.

Normal answers, recovered model errors, individual recoverable tool errors, HTTP client disconnection, foreground realtime interruption, and stopping TTS after the loop completed do not produce backend interruption notices. Canceling queued work or an already-paused task does not interrupt an active AgentLoop; the task manager handles those state changes separately.

Result delivery

Completed, failed, and cancelled tasks are delivered to the foreground model as user messages. Delivery follows three rules:

1. A terminal update starts a 500 ms sliding debounce window. Every additional update resets that window, so results finishing close together are included in one message and one foreground response.
2. An update is injected only while the foreground session is idle. It never interrupts live user speech, an active response, or a text request forwarded through the realtime chat bridge.
3. A terminal update produced while the foreground is in standby activates the foreground session, as long as the update is still pending. The manager publishes a wake signal per terminal batch, separate from the drain signal the session owns, and the daemon keeps a watermark of the manager's terminal sequence so one batch activates at most one session.

Terminal result delivery has three manager-owned phases: queued, claimed by a foreground session, and delivering. Draining claims an update but does not mark it delivered. Immediately before text injection, the foreground resolves every claimed snapshot against current manager state; after the realtime provider accepts the response request, it acknowledges the update. If the session ends first, the claim is released to the pending queue for a later session.

Calling cancel_agent_task for a completed, failed, or cancelled task preserves that historical task status but suppresses its result while the delivery is queued or claimed. A claimed result already held in the foreground's pending list is therefore removed during the final resolve and is never announced. Once delivery has begun, the provider response is the point of no return and is not retroactively interrupted by task cancellation.

A terminal task never carries a pending user action: the action is cleared when the task reaches a terminal state, so the foreground is never asked to complete an action for finished work, and teardown can tell a restored result update from a restored action request.

User action handoff

request_user_action is mode-aware:

• In an ordinary legacy run, it preserves the existing human-handoff response (HUMAN_HANDOFF_REQUESTED).
• In a background task run, it publishes a pending action while leaving the task in running. The background agent loop returns at that point, but the task is not terminal and its pending action remains queryable.

The foreground agent receives the request when it is idle and tells the user what to do on the device, including that they should say when it is complete. After the user confirms completion, the foreground calls response_user_action with the task ID and a concise user_message. The manager clears the pending action and starts another loop on the same backend runtime/session. The user_message is appended as the next user message on the existing context, so the background agent can verify the new state and continue its original task. If the realtime session ends before delivery, the pending action is retained for the next foreground session.

Updating a task while it waits for user action is different from responding to that action: the old request is no longer authoritative, so the manager clears it, invalidates any claimed foreground snapshot, and resumes the backend with the complete replacement goal.
