Foreground and Background Agents

Realtime voice mode uses two cooperating agents:

• The realtime voice model is the foreground agent. It owns the live conversation and must not wait for device operations or long-running work.
• The legacy agent loop is the background agent. It executes queued tasks one at a time with the existing runtime tools, memory, and episode recording.

The orchestration layer lives in internal/agenttask. It owns task data, state transitions, queueing, cancellation, and terminal notifications without depending on internal/agent. The daemon supplies a narrow runner adapter that maps Run(ctx, prompt) to the legacy agent.Runtime.

The two conversation contexts are persisted separately under the configured session root: sessions/user contains the realtime foreground conversation, while sessions/backend contains the legacy device-operation context. The user context also persists the realtime foreground's own tool calls and tool results, so they can be restored when a new realtime websocket session is opened. Backend tool traces remain isolated in sessions/backend; only their aggregated task updates are injected into the foreground as user messages. To keep realtime context bounded, a new websocket session replays only the latest 10 user turns, including the assistant/tool messages belonging to those turns. The full user history remains on disk.

The foreground realtime session can be activated by either the physical GPIO wakeup signal or a text request to /api/chat. A text request submitted while no realtime session is connected stays queued while the daemon connects, then becomes the first user message in that session. GPIO initialization failure does not disable /api/chat activation, which keeps the same foreground path usable on PC and other hosts without board GPIO.

An outstanding foreground response has a 60-second no-progress timeout. Accepted assistant text/audio and foreground tool calls/results renew that deadline; microphone traffic, input transcript refinements, usage reports, and stale response events do not. Foreground tools retain their separate 30-second execution timeout. An idle conversation with no pending turn is not timed out. Timeouts fail the pending text request and close the realtime session, including its playback and foreground tool context. Explicit cancellation uses the provider's ResponseInterrupter when available, stops playback and foreground tools, and retains admission ownership until the terminal acknowledgement. Late output cannot renew the cancellation deadline. Unsupported interruption, a failed write, or a missing acknowledgement closes the session; the next request then reconnects and restores history. Successful cancellation keeps supported provider sessions connected. Background tasks have their own lifecycle and are not canceled by canceling a foreground response.

Gemini interrupts through clientContent with turnComplete=false, leaving the server waiting for input rather than requesting another answer. This follows Google's ClientContent interruption semantics without switching off automatic VAD (manual activityStart requires that switch). Gemini's interrupted followed by turnComplete is normalized to a canceled terminal response; the daemon retains the interrupted response's terminal ownership even when it has no ID, without consuming the new user's pending input. See the official protocol. The empty-content cancel payload is covered by a local WebSocket protocol test; its behavior against the deployed Gemini service still requires live validation. Gemini tool-call cancellation is scoped to the listed call IDs: it cancels those foreground invocations and drops their late results while preserving other parallel calls and the response lifecycle.

Chat admission logs include the incoming and active request IDs, response ID, occupancy duration, and each admission guard. Response completion, cancellation, timeout, and session release are logged separately for diagnosing busy reports.

Foreground tools

The realtime model receives this focused catalog:

Tool	Purpose
get_current_time	Return controller-local date, time, timezone, and UTC offset.
recall_memory	Recall long-term user preferences, facts, rules, and procedures.
save_memory	Save a long-term memory without waiting for a background task.
forget_memory	Delete a saved memory by the ID returned from recall_memory.
recall_session_chunks	Recall compressed history older than the replayed window.
audio_volume	Read or set the realtime playback volume.
create_agent_task	Queue background work and return immediately with a task ID.
cancel_agent_task	Cancel queued work or request cancellation of running work.
query_agent_task	Read one task's state and result, or every outstanding task when no ID is given.
response_user_action	Resume a background task after the user completes the requested device action.
end_conversation	Return to standby after the farewell finishes playing.

create_agent_task only enqueues work. The foreground response never waits for the background agent to start or finish.

Before creating work, the foreground calls query_agent_task without a task ID and continues the task that already covers the request instead of starting a duplicate. That check answers with the tasks that are still in flight plus the finished tasks whose result has not been delivered to the foreground yet; delivered results are left out because the foreground holds them in its own context, so asking for the same work later is a genuine new request. A repeated or reworded request therefore does not start the same device work twice.

The memory tools reuse the same registrations and stores as the background agent, so both agents read and write one memory plane. Their foreground descriptions are trimmed to the foreground catalog: the background recall_memory description points at shell for raw notification records, which the realtime model cannot call.

recall_session_chunks exists because a new websocket session replays only the latest 10 user turns. Older turns stay on disk but are invisible to the foreground until recalled.

Ending a conversation

end_conversation puts the session back into standby. It does not introduce a new state: runRealtimeSession returns, and the outer loop waits for the next GPIO wakeup or /api/chat activation, exactly as it does after any other session ends.

Teardown is deferred rather than immediate, because cancelling the session as soon as the tool returns would cut off the farewell mid-sentence:

1. The tool result only records the request; the session loop owns teardown.
2. On response.done for the farewell, playback is finalized and a drain starts, bounded by a 30 s timeout.
3. Standby begins once the drain reports the speaker is empty.

The request is abandoned if the user re-engages first, via either input_audio_buffer.speech_started or a text request through the chat bridge. Both keep the session open and answer the new input instead. A text request that arrives while the farewell response is still active is queued until its response.done; during playback drain it starts immediately. While a request is pending, task updates and voice notifications are not injected, so a queued result cannot start a new response during the goodbye.

Background work is unaffected by standby. A background task that reaches a terminal state while the foreground is in standby activates the foreground by itself, so the result is reported without the user having to speak first. The existing session teardown returns undelivered task updates and pending user actions to the manager; they are delivered by the next session, whether it was started by the task update or by the user. Activation is attempted once per terminal batch: if that session cannot deliver the update, it is returned to the queue and waits for the next activation instead of re-activating in a loop. A pending user action does not activate the foreground on its own; it is announced by the next session.

Task lifecycle

Tasks use the following states:

created -> queued -> running -> completed
                            -> failed
                            -> cancelling -> cancelled
                            -> running (waiting for user action)
                 -> cancelled

Queued cancellation is immediate. Running cancellation first publishes cancelling; it becomes cancelled after the legacy runtime returns from context cancellation.

Result delivery

Completed, failed, and cancelled tasks are delivered to the foreground model as user messages. Delivery follows three rules:

1. A terminal update starts a 500 ms sliding debounce window. Every additional update resets that window, so results finishing close together are included in one message and one foreground response.
2. An update is injected only while the foreground session is idle. It never interrupts live user speech, an active response, or a text request forwarded through the realtime chat bridge.
3. A terminal update produced while the foreground is in standby activates the foreground session, as long as the update is still pending. The manager publishes a wake signal per terminal batch, separate from the drain signal the session owns, and the daemon keeps a watermark of the manager's terminal sequence so one batch activates at most one session.

Undelivered updates are returned to the pending queue if the realtime session ends. The next session can then deliver them.

A terminal task never carries a pending user action: the action is cleared when the task reaches a terminal state, so the foreground is never asked to complete an action for finished work, and teardown can tell a restored result update from a restored action request.

User action handoff

request_user_action is mode-aware:

• In an ordinary legacy run, it preserves the existing human-handoff response (HUMAN_HANDOFF_REQUESTED).
• In a background task run, it publishes a pending action while leaving the task in running. The background agent loop returns at that point, but the task is not terminal and its pending action remains queryable.

The foreground agent receives the request when it is idle and tells the user what to do on the device, including that they should say when it is complete. After the user confirms completion, the foreground calls response_user_action with the task ID and a concise user_message. The manager clears the pending action and starts another loop on the same backend runtime/session. The user_message is appended as the next user message on the existing context, so the background agent can verify the new state and continue its original task. If the realtime session ends before delivery, the pending action is retained for the next foreground session.
